PVC SUCTION & DELIVERY HOSE
Heavy Duty Grey
Structure
Hose made of spiral reinforcement of rigid PVC into fine grade soft PVC. A very sturdy suction & delivery hose for heavy duty applications. Quality PVC compounding and processing techniques have made the hose sturdy, flexible, chemical and abrasion resistant.
APPLICATIONS
Heavy duty suction & delivery of liquids, slurry, effluents and abrasive materials in industries like paper mills, cement, chemical, aquaculture, alkalies, sewerage disposal, coal & mineral mines, stone and lime quarries, projects, construction, petrochemicals, oil exploration, shipping etc. Ideal for handling saline (sea) water, light acids, alkalis and other chemicals except solvents. A heavy duty suction hose for sand pumps. For better performance of sand / mud pumps, please use the followings newly added products.
Pressure at 30℃
Working Pressure 2.5kg/cm2 to 8kg/cm2
Bursting Pressure 6kg/cm2 to 25kg/cm2
Temperature Range
60/70℃
Technical Data
| I.D. Ø (mm) | Working Pressure (kg/cm2) | Bursting Pressure (kg/cm2) | Bending Radius (mm) | Standard Length (m) |
|---|---|---|---|---|
| 25 | 8 | 25 | 48 | 30 |
| 30 | 7 | 21 | 68 | 30 |
| 40 | 5.5 | 18 | 70 | 30 |
| 50 | 4.5 | 18 | 100 | 30 |
| 65 | 4.5 | 18 | 120 | 30 |
| 75 | 4.5 | 18 | 155 | 30 |
| 100 | 4 | 14 | 213 | 15/18/30 |
| 125 | 3 | 10 | 230 | 15/18 |
| 150 | 2.5 | 9 | 375 | 15/18 |
| 200 | 2.5 | 8 | 600 | 4.5/6 |
| 250 | 2.5 | 8 | 1000 | 4.5/6 |
| 300 | 2.5 | 6 | 1000 | 4.5/6 |
